IFR chart

12V and 24V aircraft battery chargers

ground power units for aircraft
  • 12-Volt Lead-acid and Lithium-ion offers total care of LFP batteries

  • with 8 step programming

  • Automatic Battery Charger & Maintainer

  • Charge, Maintain and extend the battery life of any lithium battery

  • Quick Disconnect Harness - Easy connection to vehicle battery using battery      clips or ring terminals

  • Fully protected against reverse polarity, under / over-voltage

  • $50 / free w battery purchase

vfr sectional map

Smart charger 12V 10A battery charger is a smart
multi-stage lithium battery charger which uses the
latest switch-mode battery charging technology
and is 88% efficient
LiFEPO4 / AGM / SLA / GEL
> Full circuitry protections
> GPU mode 10A stable power
>temp controlled charging
(compare to optimate TM275)
$100

ground power units for aircraft
ground power units for aircraft

Full protection smart charger
Dual 12V 10amp or 24V 5amp mode
7 stage switch mode for any battery lithium or lead
100 - 240VAC input
minimum start 8V
micro processor controlled
fan cooled
1.3 lbs, 6.6 x 4.3 x 2.5
bright display
$75 / $50 with battery purchase

BK200 battery tester
bk200

BK200 12V and 24V aircraft battery tester is able to effectively analyze and read important  data such as voltage, internal resistance, cold cranking amps, battery health and SOC. It provides accurate results, calculates the cold cranking capability of the battery and the aging extent, allowing for a quicker, more precise assessment if the battery needs to be replaced or not.
Data is read through Bluetooth on your smart phone.
indicator; red means it is connecting,  blue indicator indicates a successful connection to battery. The interface is easy to read, and clear even in sunlight.
Copper-plated alligator clip insure more accurate testing.
Compatible with all  12 and 24V lead acid and lithium batteries.                PRICE - $25 or $10 with battery purchase.

Micro GPU Power supply

Aerolithium introduces  Micro GPU Ground Power Supplie

Providing smooth sine wave power for 14 and 28V aircraft. Perfect for updating EFIS databases and avionics testing, training, flight planning, aircraft expo's and maintenance. Use outdoors in any weather with IP67 harsh environment rating.   UL approval 62368-1 Features: LED power indicator, short circuit, overcurrent, temp, voltage, reverse polarity protections, operating temp range: -40 to 70C. 10G anti-vibration tested,These are the power supplies for commercial shops or harsh environments.
Both units utilize Switch Mode Power Supply or SMPS https://www.microchip.com/stellent/groups/SiteComm_sg/documents/Training_Tutorials/en528010.pdf


Both units carry a 3 year warranty - prices include free shipping

ground power units for aircraft

Model 2832 micro GPU   $525

Specs:

Input - 90 to 305VAC, 47 - 63Hz, 10A @115v
Output - adjustable VDC - 24 to 30V at 32A
Efficiency rating - 95%
8AWG output cable, 6 feet - or custom lengths
AN2551 3 pin oval plug  or Andersons
Dims; 1.9 x 5.7 x 12.2" weight - 11 lbs w cable

ground power units for aircraft

Model 1435 micro GPU  $400 / $450

SPECS:

Input - 90 to 305VAC, 47 - 63Hz, 7A@115VAC
Output - adjustable VDC - 13 to 15.8V at 35A - adjustable current - 18 to 35A
Efficiency rating - 94%
8AWG output cable, 6' or custom length
Anderson connector /  AN2551 oval plug
Dims: 11.0 x 5.7 x 1.9"  wt. - 7.9lb w/o cable

Aerolithium introduces a new 26V jump starter to aviation !

Aerolithium's new 26V AeroJump Pack is the simplest, lightest weight, most powerful source of emergency starting power imaginable.
Our 26V Jump Starter is the latest in lithium/supercapacitor jump technology employing the safety checks and features of any external power pack you can find.** Critical to have on cross country trips, isolated areas and especially in freezing temperatures to assist the starting battery. Don't settle for underpowered overpriced outdated units offered elsewhere. Check the size of wires; do they use smaller EC5 connectors and 10awg ?? AeroJump uses EC8 and 7awg wire. Get the most  reliable and trusted jump pack available to the aviation community. This is the Godzilla of 24V Jump Packs.  Works on Lithium or Lead acid batteries for aircraft, up to 16 liter diesel engines on boats, trucks, heavy equipment, farm equipment, etc...
Even the best lifepo4 cells will self-discharge over time, so it is suggested to keep your jump pack topped off every 4 months to keep it at 100% although it can sit for a year and still perform.
Lifecycles; supercaps are known to have 100k cycles in them.

 42,000mah size unit also available
2 year warranty 103Wh/28kmah   155Wh/42kmah   $275 / $350
Per order now and save 10% next shipment due Novemb
er




A funky video but it gets the point across; this little powerhouse starting a 16 liter Diesel engine !

** compare to -
https://www.amazon.com/
dp/B08V73BZ42?tag=baduyvn-20&linkCode=ogi&th=1&psc=1

3 pin 12V - 28V Aircraft external power plug quick connect  EC5 connector to AN2551
3 pin plug with 22" (adj ) cable    $125
($100 with battery / Aero jump purchase using EC8 heavy duty connector)
Use for other brands jump packs  using EC5

ground power units for aircraft

Lithium compatible generator / alternator

ground power units for aircraft

Alternators control the output by modulating the magnetic field of the rotor. When more current is needed to maintain bus voltage then more field current is applied and at a given RPM the output current and voltage increases.



When the alternator is spinning slowly, like at idle, and the demand for current is high, like recharging after an extended starting sequence, the alternator regulator may reach the maximum amount of field current that can be applied. In this case the alternator is current limited by the physics of the situation, where the RPM is too low to support the current demands and the bus voltage will be at less than desired until either the RPM is increased or the current demand is decreased: the field is already maxed out.



As the RPM increases the amount of power available increases, this is reflected in more current. The current output will increase until one of two things happen:

1. The regulation voltage is met and the regulator starts to reduce the field current, reducing the output current, to maintain the desired bus voltage.

2. The output is curtailed by the internal resistance of the output windings. With high RPM the output could easily be 60 amps for alternators that are otherwise rated at 40 amps. As the alternator heats up the current capability will gradually reduce from the 50%? overage down to something closer to the rated output.

The point to take away from this is that alternators typically do not have a "hard stop" current limit, if the regulation voltage is not met then they may put out substantially more current than you would expect.



At the same time, an operator should not worry about running an alternator at 100% rated output continuously. If the alternator can't do that then don't install it.



The question a builder should ask with regard to lithium batteries is why would you install a battery that wasn't compatible with my charging system? By compatible, I mean the battery must be able to take all the current that the charging system can output less the minimum expected load from the rest of the airplane. If you want to be conservative ignore the min expected load: the max current of the charging system, including the 50% overage, should be less than the maximum current the battery can take.



Alternators with lithium batteries start to work you into an undesirable corner here. The alternator *could* put out more current than you would ever want to go to the battery and you must plan for that. At the same time the alternator should be sized for the max steady state load (think, night, IFR, pitot heat on) to be no more than 80% rated output, where you can't bank on that extra 50%(or whatever it is) power being available. And you may not be able to really know what the upper limit of current is out of an alternator for planning purposes. So the 40 amp alternator is only good for 32 amps steady state but you need to plan for 60 amps charging rate being available. The problem gets worse if you have more than one power source. A few thoughts:



1. Get a battery than can charge at a rate at least 50% more than the alternator rating. 40 amp alternator? Get a battery that can take 60 amps. A 60 and a 40 amp alternator? Get a battery than can take 150 amps.



2. Get an alternator rated at 2/3rds or less of the max charge rate of the battery you are using.



3. If there is any concern about the alternator failing because it is run at 100% output for extended periods of time then get another power source. The last thing you want to be doing is tooling along in the clouds and wondering if you can run the pitot heat because you're concerned about burning up the alternator.



Either way, you shouldn't put something in your airplane that won't be compatible across all foreseeable cases. The case of concern here is having a battery that can be overwhelmed by the charging system.


An alternative: The Monkworkz generator (2.6 lbs, 30 amps) applies a current limit that is stable across operating conditions. The current limit is a "hard stop". The device directly monitors current output hundreds of thousands of times a second and reduces the output voltage until the current limit is respected. It is rated for 30 amps, and will never put out more than 30 amps. In this case, based on the 80% rule you can plan for 24 amps, and select a battery that can cope with 30 amps charge rate and your done.

Advantages

Antes de que Tesla apareciera en escena, muchas bicicletas eléctricas y scooters tenían paquetes de energía construidos con celdas de Li-ion 18650.

En comparación con la bolsa o las celdas prismáticas, las celdas cilíndricas como la 18650/26650  se puede producir más rápidamente; por lo que se producen más kWh de celda por hora debido a su configuración, otra razón para reducir los $ / kWh.

Otra ventaja de las celdas cilíndricas sobre las celdas planas (por ejemplo, de bolsa, prismática) es que sus electrodos están enrollados de manera uniforme y ajustada y encerrados en una carcasa de metal. Esto minimiza que el material del electrodo se rompa debido a las vibraciones mecánicas, los ciclos térmicos de carga y descarga, y la expansión mecánica de los conductores de corriente dentro de la celda debido a los ciclos térmicos.

Expansión de las baterías de celda de bolsa de iones de litio: observaciones de imágenes de neutrones

Jason B. Siegel4,5,1, Anna G. Stefanopoulou1, Patrick Hagans2, Yi Ding4,3 y David Gorsich3

Publicado el 27 de abril de 2013 • © 2013 The Electrochemical Society
Revista de la Sociedad Electroquímica, Volumen 160, Cita número 8 Jason B. Siegel et al 2013 J. Electrochem. Soc. 160 A103

Las baterías de aerolitio, que utilizan la forma de tipo cilíndrico de LiFePO4, tienen una densidad de energía MUY alta que produce una mayor potencia de arranque que las baterías comparables con celdas tipo bolsa.


El procesamiento especial de litio de la celda es diferente de otras celdas LiFePO4 más baratas que utilizan otras compañías de baterías. Esto da como resultado una celda más robusta que proporciona mayores mejoras de seguridad en comparación con las celdas de tipo bolsa más livianas y ofrece una mayor tolerancia al abuso a eventos como sobrecarga o pulsos cortos de descarga extrema que son comunes en el arranque de motores de aeronaves.


Otras ventajas incluyen una autodescarga muy baja, <1% al mes, lo que les da a estas células un ciclo de vida más alto, más confiabilidad y, por supuesto, ninguna posibilidad de hincharse como las células de tipo bolsa.
